Working Flow
Decoiling → Material Feeding → Roll Forming → Cutting → Collecting
Component & Technical Parameters
This part is used to support Coil.
And make the coil in a rotary way.
Bearing capacity: 5T
Inner diameter: 470-530mm
Uncoilers play an indispensable role in the production process of tile presses. In the production process of tile presses, metal sheets are usually supplied in the form of coils, and the primary function of the uncoiler is to smoothly and steadily unwind these tightly wound metal sheets.
Hydraulic Pump Station
When the equipment encounters abnormal resistance or excessive pressure, it can automatically adjust the pressure of the hydraulic system to avoid damage to the equipment due to overload, thereby improving the reliability and stability of the floor deck forming machine.
Touch Screen Control Cabinet
The control cabinet has two modes, automatic and manual modes.
The unit length of the targeted sheet and quantity can be set in the touchscreen.
The system is simple and easy to operate.
Feeding Table & Pre-Cutter
The feed table can be used as a temporary buffer and storage area, and can play a certain buffering role when the board supply speed is not completely consistent with the production speed of the tile press. For example, when the board supply is fast, the feed table can temporarily store some boards to avoid affecting the production process due to the accumulation of boards
Shaft & Roller
The wheels of the tile press usually refer to the forming rollers, which are the direct acting parts for processing the plate into trapezoidal tiles. The surface shape of these rollers is precisely processed according to the design requirements of the trapezoidal tiles. Through the gradual rolling of multiple rollers, the flat plate is gradually bent into the shape of a trapezoidal tile.
